Project Description
You can find the simplest code for whiteboard or canvas in React.
Features:
1. Change pencil color on click.
2. Erasing feature.
3. Stroke thickness
4. Data preserve on page reload
Step 1: Run command
npx create-react-app whiteboard
cd whiteboard
npm start
Step 2: Add this CSS file
#circularcursor {
background-color: transparent;
border:1px solid black;
height:25px;
width:25px;
border-radius:50%;
-moz-border-radius:50%;
-webkit-border-radius:50%;
position: absolute;
z-index: 1;
}
.canvas-btn {
position: absolute;
margin-left: 10px;
margin-top: 10px;
border-radius: 5px;
border-style: solid;
padding: 5px 5px;
border-color: gray;
border-width: thin;
}
.btn-width {
min-width: 50px;
}
.mouse-state {
cursor: none;
}
Step 3: Add Canvas,jsx file
import React, { useRef, useState, useEffect } from "react";
import "./canvas.css";
export default function Canvas() {
const [isDrawing, setIsDrawing] = useState(false);
const [color, setColor] = useState("#3B3B3B");
const [size, setSize] = useState("3");
const canvasRef = useRef(null);
const ctx = useRef(null);
const timeout = useRef(null);
const [cursor, setCursor] = useState("default");
useEffect(() => {
const canvas = canvasRef.current;
ctx.current = canvas.getContext("2d");
//Resizing
canvas.height = window.innerHeight;
canvas.width = window.innerWidth;
//Load from locastorage
const canvasimg = localStorage.getItem("canvasimg");
if (canvasimg) {
var image = new Image();
ctx.current = canvas.getContext("2d");
image.onload = function () {
ctx.current.drawImage(image, 0, 0);
setIsDrawing(false);
};
image.src = canvasimg;
}
}, [ctx]);
const startPosition = ({ nativeEvent }) => {
setIsDrawing(true);
draw(nativeEvent);
};
const finishedPosition = () => {
setIsDrawing(false);
ctx.current.beginPath();
};
const draw = ({ nativeEvent }) => {
if (!isDrawing) {
return;
}
const canvas = canvasRef.current;
ctx.current = canvas.getContext("2d");
ctx.current.lineWidth = size;
ctx.current.lineCap = "round";
ctx.current.strokeStyle = color;
ctx.current.lineTo(nativeEvent.clientX, nativeEvent.clientY);
ctx.current.stroke();
ctx.current.beginPath();
ctx.current.moveTo(nativeEvent.clientX, nativeEvent.clientY);
if (timeout.current !== undefined) clearTimeout(timeout.current);
timeout.current = setTimeout(function () {
var base64ImageData = canvas.toDataURL("image/png");
localStorage.setItem("canvasimg", base64ImageData);
}, 400);
};
const clearCanvas = () => {
localStorage.removeItem("canvasimg");
const canvas = canvasRef.current;
const context = canvas.getContext("2d");
context.fillStyle = "white";
context.fillRect(0, 0, canvas.width, canvas.height);
//Passing clear screen
if (timeout.current !== undefined) clearTimeout(timeout.current);
timeout.current = setTimeout(function () {
var base64ImageData = canvas.toDataURL("image/png");
localStorage.setItem("canvasimg", base64ImageData);
}, 400);
};
const getPen = () => {
setCursor("default");
setSize("3");
setColor("#3B3B3B");
};
const eraseCanvas = () => {
setCursor("grab");
setSize("20");
setColor("#FFFFFF");
if (!isDrawing) {
return;
}
};
return (
<>
<div className="canvas-btn">
<button onClick={getPen} className="btn-width">
Pencil
</button>
<div className="btn-width">
<input
type="color"
value={color}
onChange={(e) => setColor(e.target.value)}
/>
</div>
<div>
<select
className="btn-width"
value={size}
onChange={(e) => setSize(e.target.value)}
>
<option> 1 </option>
<option> 3 </option>
<option> 5 </option>
<option> 10 </option>
<option> 15 </option>
<option> 20 </option>
<option> 25 </option>
<option> 30 </option>
</select>
</div>
<button onClick={clearCanvas} className="btn-width">
Clear
</button>
<div>
<button onClick={eraseCanvas} className="btn-width">
Eras
</button>
</div>
</div>
<canvas
style={{ cursor: cursor }}
onMouseDown={startPosition}
onMouseUp={finishedPosition}
onMouseMove={draw}
ref={canvasRef}
/>
</>
);
}
